Aluminum Motor Housing for Testing Equipment

Home >>
Aluminum Motor Housing for Testing Equipment

Aluminum Motor Housing for Testing Equipment

Material:Aluminum 5052-H32

Finish:Brushed, deburred edges, clean surface, Light time the length of the part clear iridite

Description

High-quality sheet metal solutions. This CNC-fabricated metal enclosure is engineered for strength, functionality, and clean aesthetics. Made from corrosion-resistant aluminum, it features honeycomb ventilation for airflow, integrated standoffs, and mounting flanges for easy installation into racks, cabinets, or machines.

Rollyu Precision supplies custom aluminum 5052-H32 motor housings with a clear iridite finish, developed for use in various testing equipment assemblies. These housings offer good corrosion resistance, mechanical strength, and a clean surface, making them suitable for integration into environments where both function and appearance are important.

Production includes laser cutting, bending, punching, riveting, clinching, fastening, and deburring, followed by a clear iridite surface treatment and laser marking for part identification or traceability. Final parts are checked with dimensional inspection tools to confirm tolerance and consistency.

Parts are manufactured under ISO 9001:2015 and ISO 13485:2016 quality systems to support traceable, compliant builds for industrial and medical environments.

If you have a similar housing requirement, feel free to contact us for more details.

Process

Customized Aluminum 5052-H32 Clear Iridited Drive Motor Housing
Sheet Metal Fabrication for Testing Equipment & Automation Systems

Aluminum 5052-H32 is a high-strength, corrosion-resistant alloy widely used for custom enclosures in electromechanical testing, motion control, and R&D platforms. The clear iridite (chromate conversion) finish enhances both electrical grounding and environmental durability, making it ideal for drive motor housings and protective casings.

Material Selection and Design Review	Material: Aluminum 5052-H32 sheet (typically 1.5 mm to 3.0 mm thick) CAD models and technical drawings are reviewed for: Mounting patterns and access panels Structural reinforcement features EMC shielding and thermal management requirements
Laser Cutting	Flat sheet metal is precision-cut using a fiber or CO₂ laser machine Cutouts for connectors, fasteners, and ventilation are completed in a single pass
CNC Bending & Forming	The cut metal sheet is formed using CNC press brakes with precision dies Multiple bends and angles are applied to shape the housing enclosure
Hardware Insertion & Spot Welding	PEM fasteners, studs, or stand-offs are installed using hydraulic insertion presses Spot welding or tack welding is performed (if required for structural joins or subassemblies)
Deburring & Surface Preparation	All edges are deburred to eliminate sharpness and ensure safe handling Parts are chemically cleaned and prepped for conversion coating
Clear Iridite Surface Finish (Chromate Conversion Coating)	The housing undergoes a Type II clear chromate conversion process: Enhances corrosion resistance Provides electrical conductivity for grounding RoHS compliant and suitable for indoor/outdoor electronic use
Final Assembly, Inspection & Packaging	Functional features like mounting holes, cable grommets, and access covers are validated Visual inspection and optional CMM measurement ensure conformity to spec Units are packaged in protective material for delivery or kitting

Applications

Precision Sheet Metal Enclosures for Testing Equipment & Industrial Applications

Built from corrosion-resistant Aluminum 5052-H32 and finished with a clear iridite coating, these custom-fabricated sheet metal housings are designed to protect and support sensitive drive motors and control systems in demanding environments. Engineered for electrical conductivity, structural integrity, and lightweight performance, they’re ideal for applications requiring repeatable test conditions, precision control, and modular integration.

Industry	Application Examples
Drive Motor Enclosures in Laboratory Test Rigs	Housings for AC/DC motors or servo drives used in mechanical test benches Ensure mechanical protection and easy cable access during bench-top evaluations
Instrumentation Panels in Automated Test Equipment (ATE)	Structural brackets or outer cases for drive motors used in component testing or stress testing systems Integrated cutouts and mounting flanges for sensors, fans, and connectors
Control Boxes for Industrial Automation Testing	Lightweight sheet metal enclosures for drive controllers, motor drivers, and PLC units Modular panel integration for thermal management, wiring, and field service access
EV Drivetrain Testing Modules	Motor housing units for evaluating electric drive systems under load Incorporates vented designs or sealed panels for environmental testing
Powertrain Simulation & Fatigue Testing Systems	Enclosures for test stand-mounted motors simulating load and stress cycles Features include integrated mounting holes, stiffening ribs, and laser-etched part numbers

Specifications

Part number: RY-H0031

Materials Available: Stainless Steel, Steel, Aluminum, etc.

Tolerance: ±0.01mm

Material Certificates: Available

MOQ:1 piece

Drawing Accepted: PRO/E, Auto CAD, SolidWorks, UG, CAD / CAM / CAE, PDF

RoHS/REACH Report: Available

Certificate: ISO9001:2015, ISO13485:2016

Non-disclosure agreement: Strictly sign a confidentiality agreement NDA to give you peace of mind．

Advantage: Pre-installed standoffs for PCB or component mounting, Flanged base with keyholes for secure installation, Honeycomb ventilation for thermal management
